2 Years Quality Assurance Sealed Lead Acid Battery Charger 4.2V 8.4V 12.6V 14.4V
Output ratings
| Outout(V) | Ouptput(A) | Power | DOE VI |
| 14.4V | 2000mA | 28.8W | YES |
| 14.5V | 2000mA | 29W | YES |
| 14.6V | 2000mA | 29.2W | YES |
| 13.8V | 2000mA | 27.6W | YES |
| 14V | 2000mA | 28W | YES |
| 7.2V | 2000mA | 14W | YES |
Charge Instruction
1. Make sure your AC supply source is 100-240V and your battery pack match with the battery requirement.
2. Connect the charger to the AC outlet. LED=Green: it means power on and no battery connected.
3. Connect DC output to battery pack terminals. LED turn into red. It means in charging.
4. When LED turns Green, the battery pack is fully charged. You can charge next battery pack or switch off the power.
Notice
1. Make sure your battery voltage match with your charger.
2. Always place the charger in well-ventilated, dry environment and indoor use only.
3. Subject to change without prior notice, please contact us for the latest information.
4. Indoor used only, never expose the charger to water such as rain and splash.
5. Make sure good ventilation is provided when charger operation. Never place the charger near radiator, heat register or similar heat source when in charging.
Specifications
| NO. | Items | Specification |
| Input Characteristics | Input voltage | 100-240V~, 50/60Hz |
| Min. Input current | 0.5A |
| Output Characteristics | Max. Output Voltage | As below list |
| Max. Output Current | As below list |
| Battery Capacity | 1000mAh Min |
| Efficiency | 80% Min |
| Power Indication | LED=Green: Fully charged |
| LED=Red: In charging |
| Charging Supervision and Protection Mechanism | Over Voltage Protection | YES |
| Output Reverse Protection | YES |
| CC CV | YES |
| Envrionment | Operation Temperature | 32-140F |
| Operation Humidity | 20-85% |
| Storage Temperature | 40-80F |
| Storage Humidity | 10-95% |
| Mechanical | Dimension | --- |
| AC Plug | EU US UK AU KR JP CN |
| Weight | 110G |
| Output Cable | 1.2m 2464 24AWG |
| Connector | 5.5x2.1mm (Customizable ) |
FAQ
1. Q: Are you a factory?
A Yes,We are a professional usb charger,battery charger, power adapter manufacturer in Shenzhen
2. Q: How many employees in your factory?
A We have two factoreis total about 300 employees,professional production people,QC ,experienced R&D engineers and passional sales.
3. Q: How to guarantee quality?
A:Components come from famous factories, professional QC department,4 hours full load 100% burn-in
4. Q: Do you provide the free samples?
A: Yes, usually 1-2 samples.
5. Q: What is your lead time?
A: Samples 1-3 days, Mass production 15days
6. Q: What is your warranty?
A: 3years Warranty
7. Q: What are the payment terms:
A: T/T, Payapl, Western Union,L/C.
